FUME HOOD

Fume Hood

Chemical fume hood, when used properly, are one of the most reliable engineering controls in the laboratory. They protect workers by: Containing vapours, dusts, gases, and fumes generated within the hood, and removing them as air flows into the hood and then out via the laboratory exhaust system. We are manufacturer, supplier and exporter of Fume Hood in Mumbai, India to all over the world with superior designed.

TYPES OF FUME HOOD

  • Bench Type Fume Hood
  • Low Bench Type Fume Hood
  • Walk in Type Fume Hood

Specifications

MOC MILD STEEL/STAINLESS STEEL
STD SIZES 1.2 M (L) X 1.8 M (L) X 2.4 M (L) X 0.915 M (W) X 2.3 M (H)
BODY BODY STRUCTURE MADE FROM 18 SWG (1.2 mm)
STURCTURE INNER LINING OF REAR & TOP BAFFLES IN 6 MM THICK PHENOLIC RESIN CONSTRUCTION SHOULD BE CHEMICAL & HEAT RESISTANT WITH SMOOTH FINISH
BASE CABINET SHUTTERS WITH SHELVES 18SWG(1.2MM).
Working Top Black Jet Granite 20mm with 20mm skirting covered, 1No. Oval shaped cup sink in PP for drainage water.
Shash 5mm Toughened glass with vertical rising shutter
Air foil AERODYNAMIC TYPE
VALVES Air/Nitrogen/Vaccum/Water
DUCT DAMPER Min 200mm Diameter in PP construction complete with flanges with both sides & manual operation handle
DUCT DAMPER Min 200mm Diameter in PP construction complete with flanges with both sides & manual operation handle.
ELECTRICAL PANEL 5A MCB Switch For Fluorescent Light SA/16A MCB Switches & Sockets
